LFK 6000 X
Cod. 02011602
EAN 8422248357180
INFORMACIÓN GENERAL
EAN/UPC
8422248357180
Subfamily
Conventional
Product fiche according to directives EU65/2014 - EN61591, EN60704-2-13, EN50564
AEC (Energy consumption per year) (kWh/año)
29,6
EEI class (Energy efficiency class)
B
FDE (Fluid dynamic efficiency)
11,5
FDE class (Fluid dynamic efficiency class)
E
LE (Light efficiency) (lux/W)
15,5
LE class (Light efficiency class)
D
GFE (Grease filtering efficiency)
67,7
GFE Class (Grease filtering efficiency class)
D
Normal mode airflow MIN (m3/h)
108
Normal mode airflow MAX (m3/h)
162
Normal mode acustic power MIN (dB)
49
Normal mode acustic power MAX (dB)
58
Po (Off-mode power consumption) (W)
0
Ps (Stand-by power consumption) (W)
0
Integration directive EU 66/2014
ƒ (Factor Increase in the time)
1,6
EEI (Energy efficiency Index)
69,2
QBEP (Maximum airflow point efficiency) (m3/h)
91,5
PBEP (Maximum pressure point efficiency) (Pa)
211,9
WBEP (Electrical power consumption at maximum efficiency) (W)
47
WL (Rated power lighting system) (W)
3
EMIDDLE (Average illuminance on the cooking surface) (lux)
46,5
External Dimensions
Width (mm)
600
Depth (mm)
425
Maximum Total Height (mm)
85
Minimum Total Height (mm)
85
Outlet Diameter (mm)
120
Characteristics
Motor Quantity
1
Motor Model
L1N
Maximum Pressure (Pa)
318
Filter Technology
Achrylic
Control Tecnology
Mechanical rocker switch
Booster
-
Power levels
3
Timer
-
Filter Saturation Indicator
-
Charcoal Filter Change Indicator
-
Dimmer Function
-
Connectivity
-
Remote control
-
Display
-
Lighting
Light Model
LED E-14
Lightning Technology
LED
Installation
Minimum distance to an electric cooktop (mm)
550
Minimum distance to a gas cooktop (mm)
650
Recirculation Option
√
Charcoal Filter
-
Back Draught Shutter
-
Inner shield
-
Electric Connection
Rated voltage (V)
220-240
Rated frequency (Hz)
50
Rated power input (W)
65,5
Protection against electric shock
Class I
Plug type
No plug
Accessories
Upper Decorative Duct Extension
No
White Decorative Duct
No
Black Decorative Duct
No
Island Tube Enhancer
No
Back Draught Shutter
'02849002
Active Charcoal Filter
'02846764
